D-SOAR Plus-G Ultra-High Power Fiber Laser Cutting Machine With Bevel Head

D-Soar Plus-PG ultra-high power fiber laser cutting machine is specifically configured for high-end customers, and the whole machine is designed and debugged by DNE LASER. The main components are imported, with higher cutting accuracy, faster speed, easier operation, lower use cost and wider cutting material range. By ingeniously adding two rotating axes to the conventional laser cutting head, the angle range is expanded from 1° to ±45°. This innovative feature enables the creation of various slope shapes​, such as V groove, Y groove, and X groove. These advancements not only facilitate the welding of thick plates and streamline the workflow but also result in significant time and labour cost savings.

price request
  • Fully enclosed protective cabin meets national safety standards.
  • Feature the capacity for ±45° bevel cutting, supporting V, X, Y, and K bevel types.
  • Accurate control of gas consumption,with low use cost and quick return on investment.
  • Safe and reliable active defense system, anti-collision protection, intelligent stroke control and intelligent alarm function.
  • Customized bus control system, integrated high-efficiency nesting software,cutting program will be faster and more conveniently.
  • Equipped with high-torque servo motor and high-precision imported reducer,with high efficiency, good dynamic characteristics, and high cutting precision.
